Hardware connections are important components in bicycles that connect the frame to front forks, cranks, and other parts. Here are some practical installation tips:

Preparation before installation

Check parts: Carefully inspect the five joints and related parts, such as the central shaft, crankshaft, etc., to ensure that there are no damaged, deformed or missing components. The internal threads of the five joints should be intact and undamaged. If there are defects, replace them in a timely manner.

Cleaning components: Use a clean cloth to wipe the inner holes of the five way valve, the surface of the central axis, and other mating parts to remove oil, dust, and impurities, avoiding wear or affecting installation accuracy during installation.

Prepare tools: Prepare suitable tools such as a five way wrench, center axle wrench, torque wrench, etc. Ensure that the tool size matches the parts to ensure a smooth installation process.

setup script

Install the central axis: If it is a press fit five way joint, apply an appropriate amount of lubricating grease to the inner hole of the five way joint and the outer shell of the central axis to reduce installation resistance and prevent rust. Align the central axis correctly with the inner hole of the five way connector, use a specialized pressing tool, and apply even force to press the central axis into the five way connector, ensuring that the central axis is installed in place and the exposed lengths on both sides are equal. If it is a threaded five way joint, apply a small amount of anti loosening glue on the thread of the central axis, and then use a five way wrench to screw the central axis into the five way joint. Pay attention to the correct direction of rotation and gradually tighten it evenly to avoid unilateral tightening that may cause the central axis to be installed improperly.

Install the crankshaft: Install the crankshaft onto the central axis, paying attention to the installation direction and position of the crankshaft. Generally speaking, there will be markings or specific installation position indications on the crankshaft. Use a crank wrench to tighten the fixing bolts of the crankshaft, and tighten them according to the specified torque value to ensure that the crankshaft is securely installed and will not loosen during riding. Some high-end cranks may require the use of special tools or installation methods, and must be operated according to the product manual.

Adjust chain tension: After installing the crank, install the chain and adjust its tension. The appropriate chain tension should ensure normal transmission of the chain during cycling, without causing excessive looseness, jumping teeth, or increasing transmission resistance and wear due to excessive tension. Usually, the tension of the chain can be changed by adjusting the position of the rear wheel axle. After the adjustment is completed, ensure that the rear wheel is installed firmly and in the correct position on the frame.

Check after installation

Check component connections: Recheck if the connections of the five links, central axis, crankshaft, and chain components are secure, and if all bolts and nuts are tightened to the specified torque values. You can gently rotate the crankshaft to check if the central axis rotates smoothly, whether there is any jamming or abnormal noise.

Check the operation of the chain: Rotate the crank to drive the chain to run, observe whether the chain runs smoothly on the sprocket and flywheel, and whether there is any deviation, jumping teeth, or friction with other components. If there are any problems, adjust the chain or check the installation position of related components in a timely manner.

Check overall performance: Place the bicycle on the ground, simulate the riding state, and check the stability and reliability of the five joints and related components under stress. You can gently shake the bicycle and observe whether there is any looseness or abnormality in the five joints to ensure the safety and comfort of the bicycle during riding.
